Poste :
HL-A018

Bande LED pour plafond - Profilé d'éclairage suspendu en aluminium HL-A018

⚡ Quick Turnaround: 5-7 Days for Custom Lengths

Modèle : HL-A018

Profile size:W:16mm * H: 10mm

PCB width: 33 mm

Installation:Ceiling Mount, Suspended Mount, Surface Mount

REQUEST A BULK QUOTE Download PDF Spec

1-Year Warranty | CE & RoHS Certified.

Wholesale Pricing Available Upon Request

Spécifications techniques

Modèle :

HL-A018

Profile size:

L:16mm * H : 10mm

PCB width:

33 mm

Installation :

Montage au plafond, montage suspendu, montage en surface

Matériau :

AL6063+PC

IP Rating (Profile):

IP20 / IP44 (Depends on strip used)

Surface:

Anodisé/peinture

Standard Length:

1m / 2m / 3m / 4m

Compatible Accessories :

PC Diffuser, End Cap, Clip, Suspended Rope, Connector

Compatible Accessories System

HL-A018 End Cap

HL-A018 End Cap

A001 cover

A001 cover

Suspended Rope HL-DS004

Suspended Rope HL-DS004

M1 clip

M1 clip

EnterMedia Studios, Toronto Wide Suspended Studio Lighting

City: Toronto, Canada

A content studio using the HL-A018 wide suspended profile (33 mm source) with aluminium/stainless clip options per zone climate. AL 6063 anodised silver, PC/PMMA cover (A001), 4 m stock. 620 m installed; broadcast calibration passed within ±3% colour temperature.

Case Detail
  • Dot-Free Diffused Glow
  • 6063-T5 Premium Aluminum
  • Supporting precise field cutting or factory pre-cuts.
Fabricant de profilés LED

Wholesale/purchasing process

Ready to integrate this profile – HL-A018 into your project? Check our procurement guide below.

01

Consulter le service clientèle

Fournir un service clientèle en ligne 24 heures sur 24.

02

Confirmer la demande

Veuillez indiquer au service clientèle le modèle, la nomenclature, la quantité et les exigences de personnalisation des produits dont vous avez besoin. Nous résoudrons tous les problèmes pour vous.

03

Commande

Après avoir déterminé vos besoins, notre service clientèle vous aidera à passer votre commande, de sorte que vous n'ayez aucune inquiétude à avoir.

04

Assurer la livraison

Nous disposons des canaux d'expédition appropriés, mais vous pouvez bien entendu spécifier votre propre service d'expédition.

05

Livraison

Vous recevrez bientôt les produits que vous avez achetés.

06

Sortie de caisse

Prise en charge de T/T, Paypal, carte de crédit, acceptation bancaire, etc.

Is this HL-A018 profile the you are looking for?
Contactez-nous dès aujourd'hui et nous vous aiderons du mieux que nous pouvons !

Demander un devis
Fabrication de profilés LED Helian
Fabrication de profilés LED Helian

FAQ

Peut-être souhaitez-vous également connaître ces informations lors de l'achat en gros ou de la personnalisation des canaux lumineux LED.

Our standard warehouse stocking lengths are 1.0m, 2.0m, and 2.5m. For large-scale architectural projects, we provide professional precise factory-cutting services. You can submit your detailed shop drawings to our engineering team to get pre-cut profiles at specific lengths or 45-degree mitered angles to reduce on-site installer labor.
All Helian linear channels are extruded from architectural-grade 6063-T5 aluminum alloy with an anodized surface treatment. This structural configuration offers high thermal conductivity, successfully serving as a heavy-duty heat sink. It efficiently dissipates heat generated by high-density flexible or rigid LED strips up to 15W/m, preventing lumen depreciation and extending the LED lifespan over 50,000 hours.
We strictly use premium, UV-stabilized Polycarbonate (PC) or optical PolyMethyl Methacrylate (PMMA) from Tier-1 global raw material suppliers. Our frosted/opal covers ensure up to 85% light transmittance, and our specialized clear optical lenses exceed 90% transmittance. The raw materials are UV-protected, ensuring the diffuser will not yellow, crack, or turn brittle during long-term continuous operation in commercial lighting indoor environments.
By default, each standard packaging unit includes 2 end caps (1 blank, 1 with a wire hole) and 2 standard metal mounting clips per meter. For specific structural mounting methods—such as suspended spring clips, drywall mud-in components, or linear continuous connectors—please consult our project specialists. To guarantee optimal performance, please check the "Lighting Source Width" parameter listed in our specifications table to ensure your LED strip's outer PCB fits perfectly inside the inner aluminum track.
