HL-BAPL006

16mm LED Aluminium Corner Profile – V-Shape Channel for Cabinet Edge Lighting

🟢 In Stock & Ready for Rapid Dispatch (Standard Qty)

Model: HL-BAPL006

Profile size:W:16mm * H: 16mm

PCB width: 10 mm

Installation:Corner Profiles

REQUEST A BULK QUOTE Download PDF Spec

100% Virgin Aluminum (No Recycled) – Better Cooling, Longer Lifespan. CE & RoHS.

Wholesale Pricing Available Upon Request

BAPL006 Dimension drawing

Technical Specifications

Model:

HL-BAPL006

Profile size:

W:16mm * H: 16mm

PCB width:

10 mm

Installation:

Corner Profiles

Material:

Aluminum 6063 +PC/PMMA

IP Rating (Profile):

IP20 / IP44 (Depends on strip used)

Surface:

Anodized/Painting

Standard Length:

1m / 2m / 3m / 4m

Compatible Accessories :

PC Diffuser, PMMA Diffuser, End Cap, Clip, Connector

Compatible Accessories System

006 Cover

006 Cover

006 End Cap

006 End Cap

005/006 Stainless Steel Clips

005/006 Stainless Steel Clips

Black profile lighting

Black anodizing lets the channel vanish against dark surfaces, leaving just the light.

  • Dot-Free Diffused Glow
  • 6063-T5 Premium Aluminum
  • Supporting precise field cutting or factory pre-cuts.

Is this HL-BAPL006 profile the led aluminium corner profile you are looking for?
Contact us today, and we will help you however we can!

Get a quote now
Helian LED profiles manufacture
Helian LED profiles manufacture

FAQs

Perhaps you would also like to know the information when purchasing in bulk or customizing LED light channels.

Yes. We support sample orders. Contact our sales team with your required model numbers, and we will arrange sample delivery for your evaluation.
Yes. Our standard aluminum profiles come in 4-meter lengths. For bulk project orders, we provide factory precision cutting to your required lengths. Simply provide your cut list or shop drawings.
European market: CE & ROHS certified. North American market: UL certified.
Aluminum body: 6063-T5 aluminum alloy, available with anodized or painted surface finish.

Diffuser cover: PC (opal, transparent) or PMMA (milky white, transparent, semi-transparent). Both materials are UV-stabilized and resist yellowing during long-term commercial use.
Check the "Lighting Source Width" parameter on each product's specification sheet. Your LED strip's PCB width must be equal to or smaller than this value. Our profiles support PCB widths from 5mm to 185mm, depending on the model.
Each profile includes compatible end caps, mounting clips (stainless steel or aluminum), and optional suspended rope sets. Diffuser covers are ordered separately. For drywall mud-in or suspended ceiling installation, check the structure diagram in the product spec sheet.
